DEMI X 520™ for Dental PolyJet

When precision and efficiency matter most, the PostProcess™ DEMI X 520 for Dental PolyJet sets a new standard in automated post-processing for PolyJet support removal. Engineered to deliver unparalleled results, this innovative full-stack solution combines cutting-edge technology, intelligent software, and specially formulated chemistry to optimize your dental lab’s post-printing workflow.

  • Fast processing speeds
    With a 2 minute operator time and batch processing hundreds of parts, you can achieve significant labor time savings and minimize lab technician time.
  • Reduced Manual Labor
    Minimize manual labor and operator error with automated cleaning, providing high-quality and consistent results every time.
  • Enhanced safety
    Automated lift and safety enclosure ensures uniform chemistry exposure for PolyJet support removal, providing maximum technician protection.
  • Increased throughput
    DEMI X 520 can seamlessly process large dental batch sizes, enabling high volume production, with hundreds of parts processed in a single cycle.
  • Repeatable results
    Axial Flow Technology™ allows for adjustable flow, reducing the risk of part damage to guarantee consistent results, even with complex dental parts.
  • Full software integration
    AUTOMAT3D® digital platform allows for full customization, recipe storage and automation with one-touch operation.

Download the PDF specifications.

Contact us to learn more

Specifications

Electrical Requirements:

  • US | 120 Volt, 60Hz, 3-Phase
  • EU | 230 Volt, 50 Hz, 3-Phase

Envelope Capacity:

  • 14″ L x 14″ W x 15″ H (36 x 36 x 39 cm)

Lift Capacity:

  • 10 lbs (4.5 kg)

Consumable Used:

  • PLM-101-SUB

Consumable Capacity:

  • 24 gallons (91 liters)

Machine Dimensions (WxDxH):

  • Doors Closed: 32” L x 25” W x 67” H (82 x 64 x 170 cm)
  • Doors Open: 54.6” L x 28.9” W x 67.8” H (139 x 73 x 172 cm)

System Weight:

  • Empty: Approx. 325 lbs (147 kg)
  • Full: Approx. 525 lbs (238 kg)

System Warranty:

  • 12 months on-site service and support, as per PostProcess Technologies conditions of sale.

Environmental Requirements:

  • Temperature range: 60-80°F (15-27°C)
  • Relative humidity: 0-80%

Software:

  • AUTOMAT3D, Windows 10

Regulatory Conformity:

  • CE, SGS

Features & Options:

  • Customizable settings with recipe storage capability / Ability to clean parts and trays simultaneously on or off platform

Safety Features:

  • Emergency stop / Safety enclosure with door sensor

Connectivity:

  • USB Port: USB 3.1
  • Ethernet: Fully compliant with IEE 802.3, IEEE 802.3u, IEEE 802.3ab

Material Compatibility:

  • Effectively removes SUP7111, SUP705, SUP706, SUP710 support material

Printer Compatibility:

  • Stratasys J3 DentaJet, J5 DentaJet, DentaJet XL
